MATRIX830-164WSR0,16Mp,16MM,F/4,W,RS
The Matrix 830 16MP are Datalogic’s next-generation industrial 2D
barcode readers, purpose-built for high-speed transportation and logistics automation
applications. These devices set a new benchmark in performance, system cost efficiency, and ease of integration.
-
Description
FEATURES
• 16 MP image sensor, up to 30 FPS at full resolution
• Patented dynamic, Sequential, or SW adjustable focus system offering extended depth of field
• Continuous, no-flashing white illumination, with a rectangular shape to optimize reading on wide belts
• Region Of Interest Windowing for higher frame rate
• Next generation decode algorithm for outstanding decoding capability on 1D, 2D, Stacked, or Postal
Symbologies
• Gigabyte Ethernet for high-speed connectivity
• PackTrack capability for closer item spacing
• Multiple format image saving from full definition to a highly compressed .jpg
• Datalogic’s 360-degree bezel feedback technology with programmable colors provides multiple
options for visual feedback
• Dual laser aiming for ease of installation e-GENIUS browser-based interface compatible with any kind
of operating system and hardware platform including PC’s and Tablet
• Extreme Industrial grade: IP65 for harsh environments with 0 to 50 °C / 32 to 122 ºFoperating
temperatures - Files
DS-MATRIX830-EN.pdf
