Vibr.sens. xyz,RS485+I/V,cable
Vibration, shock and inclination sensor, 3-axis, RS485 + Analogue, 2m cable exit, 2D FILES, FILE 3D, CAD FILES, EU DECLARATIONS, SERIES CATALOGUE, USER MANUALS, SENSOR SOFTWARE
Orderable item
-
Description
- M18 housing
- AISI316L stainless steel housing (front included)
- IP67 protection degree
Detection properties Operative range ± 2g; ± 4g; ± 8g; ± 16g (selectable) Resolution 15,62mg @ ± 2g 31,25mg @ ± 4g 62,50mg @ ± 8g 125mg @ ±16g Detection Axes 3 (X, Y, Z) Application Technology MEMS Outputs Output type Digital + Analogue (I/V selectable) Output Function Vibration amplitude Digital Output RS485 57600 baud rate - 1 bit stop - no parity Voltage Analogue Output 0…5V / 0…10V (selectable) Current Analogue Output 4…20mA / 0…20mA / 0…24mA (selectable) Electrical data Operating Voltage 19,2 … 28,8 Vdc LED indicators Green: Run mode Yellow: writing/programming memory Blue: transit of RS485 packet data Red: Interrupt active Reverse Polarity Protection Yes Impulsive Overvoltage Protection Yes Power Consumption < 1 W Frequency Range 0 … 400Hz Digital Resolution 16 bit @RS485 (complementary to 2) Analogue Resolution 12 bit Load Resistor (Voltage) 1kΩ … 1MΩ Load Resistor (Current) 100 … 500Ω Mechanical data Dimensions M18 Housing Material Stainless steel AISI316L (body) Grilamid (cable exit) Connections 2 m - 5 poles cable Active Head Material Stainless steel AISI316L Operating temperature -25°C …+70°C Storage temperature -30°C … + 90°C (without ice) humidity < 80% (without condensation) Test/Approvals Approvals CE Degree of protection IP67 Accessories Supplied Accessories 2 x nuts Generical Data Dimensions M18 Operating Temperature -25°C …+70°C Humidity < 80% (without condensation) Mechanical Protection IP67 -
