Photo.d10,IR emiss.,Cabl,Emitt

Photo.d10,IR emiss.,Cable,Emitter
Photoelectric sensor Em. 60m D.10 mm L46 mm AL Vtr 10 m

Article no.: DGE/00-1B
Orderable item
Register
  • Description
    Overview The unit allows the mouting of miniature pair of sensors suitable for very harsh environments (DG series) LED indicators: alignment (stability), operating voltage, alarm and output state Operating voltage AC or DC Relay output and relay alarm output Double timer with indipendent adjustments Sensitivity adjustment Possibility of mounting on panel IP68 photoelectric sensors for applications in harsh environment Sensing distance 60 m (HI), 30 m (LO) Approvals: CE

    Technical Features

    Detection properties
    Nominal sensing distance 60m
    Beam angle ± 5°
    Application
    Function Principle Emitter
    Optic position Axial
    Electrical data
    Operating Voltage from UR control unit
    Emission Infrared
    Interference to external light 20000 lux
    Mechanical data
    Dimensions Ø 10mm x 46mm
    Housing Material Anodized alluminium
    Connections 10m PVC cable
    Active Head Material glass
    Operating temperature -20°C … +60°C
    Diameter/Dimension Ø 10mm
    Test/Approvals
    Approvals CE
    EMC compatibility Conforming with EMC directive according with EN60947-5-2
    Degree of protection IP67
    Generical Data
    Dimensions Ø 10mm x 46mm
    Operating Temperature -20°C … +60°C
    Mechanical Protection IP67
