Photo.M18,PNP-NO,M12Plug,Rec

Name: Photo.M18,PNP-NO,M12Plug,Rec
SKU: SPG/AP-0E
Availability: BackOrder

Photo.M18,PNP-NO,M12 plug,Receiver
Photoelectric sensor M18 Receiver 8 m NO/PNP conn.M12 plast.

Article no.: SPG/AP-0E

Orderable item

Overview Models with side sens. adjustment on axial and right angle optic LO/DO selectable output ATEX models, cat. 3, available on request LED status indicator for all versions Complete protection against electrical damages IP67 protection degree for all models Approvals: CE and cULus listed

Technical Features

Detection properties

Nominal sensing distance	8m
Thermal drift of Sr	≤10% Sr
Repeat Accuracy	5%
minimum detectable object	Ø 4mm
Sensitivity adjustment	No

Application

Function Principle	Receiver
Emitter/Receiver	Receiver
Optic position	Radial 90°

Outputs

Output type	PNP NO
Output Function	NO
Switching frequency	250Hz
Response time	2ms

Electrical data

Operating Voltage	10…30VDC
No-Load supply current	≤ 20mA
Load current	≤100mA
Leakage current	≤10μA
Output voltage drop	≤2,5V@Iload=100mA
Max ripple content	≤10%
LED indicators	Yellow (status output)
Time delay before availability	≤200ms
Short-circuit protection	Yes
Reverse Polarity Protection	Yes
Emission	LED Red (660nm)
Interference to external light	5000lux (incandescent lamp), 10000lux (sunlight)
Impulsive Overvoltage Protection	Yes

Mechanical data

Dimensions	M18 x 1 /L =75,7mm
Weight	30g
Housing Material	PBT / PC plug
Connections	M12 plug
Active Head Material	PMMA
Tightening torque	1Nm
Operating temperature	- 25°C…+ 70° C (Without freeze)
Diameter/Dimension	M18

Test/Approvals

Approvals	CE cULus
EMC compatibility	EN 60947-5-2
Shocks and vibrations	Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
Degree of protection	IP67

Accessories

Supplied Accessories

nuts M18 x 1, screwdriver

Generical Data

Dimensions	M18 x 1 /L =75,7mm
Operating Temperature	- 25°C…+ 70°C (Without freeze)
Mechanical Protection	IP67
