M18,RED emis,,Cable 90°,Emitt

Photo.M18,Red emis.,Cable 90°,Emitter
Photoelectric sensor M18 Emitt. RED emission narrow beam cable 2m 90° metal.

Article no.: SSU/00-1C
Orderable item
Register
  • Description

    Technical Features

    Detection properties
    Nominal sensing distance 3m (SSU), 8m (SSG)
    Thermal drift of Sr ≤10% Sr
    Repeat Accuracy 5%
    Sensitivity adjustment No
    Application
    Function Principle Emitter
    Emitter/Receiver Emitter
    Optic position Axial
    Outputs
    Output type
    Electrical data
    Operating Voltage 10…30VDC
    No-Load supply current ≤ 25mA
    Max ripple content ≤10%
    LED indicators Yellow(powerON)
    Time delay before availability ≤200ms
    Short-circuit protection Yes
    Reverse Polarity Protection Yes
    Emission LED Red (660nm)
    Impulsive Overvoltage Protection Yes
    Mechanical data
    Housing Material Nickel plated brass / PC cable exit
    Connections 2m PVC cable 90°
    Active Head Material PMMA
    Tightening torque 25Nm
    Diameter/Dimension M18
    Test/Approvals
    Approvals CE cULus
    EMC compatibility EN 60947-5-2
    Shocks and vibrations Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
    Accessories
    Supplied Accessories nuts M18 x 1
    Generical Data
    Dimensions M18 x 1/L=63,9mm
    Operating Temperature - 25°C…+ 70°C (Without freeze)
    Mechanical Protection IP67
