M18,PNP-NC,Cabl 90°,Receiver

Photo.M18,PNP-NC,Cable 90°,Receiver
Photoelectric sensor M18 Receiver 8 m NC/PNP cable 2m 90° metal.

Article no.: SSG/CP-1C
Orderable item
Register
  • Description

    Technical Features

    Detection properties
    Nominal sensing distance 8m
    Thermal drift of Sr ≤10% Sr
    Repeat Accuracy 5%
    minimum detectable object Ø 4mm
    Sensitivity adjustment No
    Application
    Function Principle Receiver
    Emitter/Receiver Receiver
    Optic position Axial
    Outputs
    Output type PNP NC
    Output Function NC
    Switching frequency 250Hz
    Response time 2ms
    Electrical data
    Operating Voltage 10…30VDC
    No-Load supply current ≤ 20mA
    Load current ≤100mA
    Leakage current ≤10μA
    Output voltage drop ≤2,5V@Iload=100mA
    Max ripple content ≤10%
    LED indicators Yellow (status output)
    Time delay before availability ≤200ms
    Short-circuit protection Yes
    Reverse Polarity Protection Yes
    Interference to external light 5000lux (incandescent lamp), 10000lux (sunlight)
    Impulsive Overvoltage Protection Yes
    Mechanical data
    Housing Material Nickel plated brass / PC cable exit
    Connections 2m PVC cable 90°
    Active Head Material PMMA
    Tightening torque 25Nm
    Diameter/Dimension M18
    Test/Approvals
    Approvals CE cULus
    EMC compatibility EN 60947-5-2
    Shocks and vibrations Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
    Accessories
    Supplied Accessories nuts M18 x 1
    Generical Data
    Dimensions M18 x 1/L=63,9mm
    Operating Temperature - 25°C…+ 70°C (Without freeze)
    Mechanical Protection IP67
