Photo.M8,PNP-NC,M8,Receiver

Name: Photo.M8,PNP-NC,M8,Receiver
SKU: HER/CP-3F
Availability: BackOrder

Photo.M8,PNP-NC,M8 plug,Receiver
Photoelectric sensor Receiver M8 10-30Vdc PNP NC 10Khz 1m conn.M8

Article no.: HER/CP-3F

Orderable item

Overview M8 through beam models with high switching frequency LED status indicator for all models Complete protection against electrical damages IP67 protection degree Stainless steel housing Supply voltage 10...30 Vdc Approvals: CE

Technical Features

Detection properties

Nominal sensing distance	1m
Thermal drift of Sr	≤10%Sr
Repeat Accuracy	≤10%
Sensitivity adjustment	No

Application

Function Principle	Receiver
Emitter/Receiver	Receiver
Optic position	Axial

Outputs

Output type	PNP NC
Output Function	NC
Switching frequency	10Khz
Response time	50 µs

Electrical data

Operating Voltage	10…30VDC
No-Load supply current	≤45mA
Load current	≤100mA
Leakage current	≤10µA
Output voltage drop	≤2V@Iload=100mA
Max ripple content	≤10%
LED indicators	Yellow (status output)
Time delay before availability	≤200ms
Short-circuit protection	Yes
Reverse Polarity Protection	Yes
Emission	LED Infrared (880nm)
Interference to external light	3.000 lux (incandescent lamp), 5.000 lux (sunlight)
Impulsive Overvoltage Protection	Yes

Mechanical data

Dimensions	M8x0,75/L=49mm
Weight	15g
Housing Material	Stainless Steel AISI 303
Connections	M8 plug 3pin
Active Head Material	PMMA
Operating temperature	- 25°C…+ 50° C (without freeze)
Diameter/Dimension	M8

Test/Approvals

Approvals	CE
EMC compatibility	EN 60947-5-2
Shocks and vibrations	Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
Degree of protection	IP67

Accessories

Supplied Accessories

nuts M8 x 0,75

Generical Data

Dimensions	M8x0,75/L=54mm
Operating Temperature	- 25°C…+ 70°C (Without freeze)
Mechanical Protection	IP67
