Photo.M18,NPN-NO/NC,M12,Diff

Photo.M18,NPN-NO/NC,M12 plug,Diffuse
Photoelectric sensor M18 Axial Diffuse 800 mm adj. NPN L/D conn. M12

Article no.: FFI8/0N-1E
Orderable item
Register
  • Description
    Overview

    Technical Features

    Detection properties
    Nominal sensing distance 800mm
    Thermal drift of Sr 10% Sr
    Repeat Accuracy 5%
    Sensitivity adjustment Teach-in
    Application
    Function Principle Diffuse reflection (long distance, >600mm)
    Notes white target Kodak 90% 400 x 400mm
    Optic position Axial
    Outputs
    Output type NPN L/D Selectable
    Output Function L/D Selectable
    Switching frequency 500Hz
    Response time 1ms
    Electrical data
    Operating Voltage 10…30VDC
    No-Load supply current ≤ 35mA
    Load current ≤100mA
    Leakage current ≤10μA
    Output voltage drop ≤2V@Iload=100mA
    Max ripple content ≤10%
    LED indicators Green Stability ; Yellow Output state ,
    Time delay before availability ≤200ms
    Short-circuit protection Yes
    Reverse Polarity Protection Yes
    Emission LED Infrared (880nm)
    Interference to external light 5.000lux (incandescent lamp), 10.000lux (sunlight)
    Mechanical data
    Dimensions M18x1/L=83mm
    Weight 60g
    Housing Material Stainless steel AISI 316L / PA12 plug
    Connections M12 plug
    Active Head Material PA12
    Tightening torque 50Nm
    Operating temperature -25°C…+80°C (without freeze)
    Diameter/Dimension M18
    Test/Approvals
    Approvals CE cULus ECOLAB Diversey
    EMC compatibility EN 60947-5-2
    Shocks and vibrations Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
    Degree of protection IP68, IP69K
    Accessories
    Supplied Accessories Nuts M18 x 1
    Generical Data
    Dimensions M18x1/L=83mm
    Operating Temperature - 25°C…+ 80°C (Without freeze)
    Mechanical Protection IP68, IP69K
