Ph.d 18,NPN-NO+NC,M12Plug,BGS

Photo.d 18,NPN-NO+NC,M12 plug,BGS
Photoelectric sensor M18 Axial Background suppression 30-130 mm NPN NO+NC housing smooth

Article no.: FFRS/BN-1EV5
Orderable item
Register
  • Description
    Overview

    Technical Features

    Detection properties
    Nominal sensing distance 130mm
    Repeat Accuracy 10%
    Sensitivity adjustment Teach-in
    Minimum sensing distance (blind zone) 30mm
    Application
    Function Principle Blackground suppression
    Notes white target Kodak 90%100 x 100mm
    Optic position Axial
    Outputs
    Output type NPN NO+NC
    Output Function NO+NC
    Switching frequency 1Khz
    Response time 500µs
    Electrical data
    Operating Voltage 10…30VDC
    No-Load supply current ≤ 50mA
    Load current ≤100mA
    Leakage current ≤10μA
    Output voltage drop ≤2V@Iload=100mA
    Max ripple content ≤10%
    LED indicators Green Stability ; Yellow Output state ,
    Time delay before availability ≤200ms
    Short-circuit protection Yes
    Reverse Polarity Protection Yes
    Emission LED Red (660nm)
    Interference to external light 5.000lux (incandescent lamp), 10.000lux (sunlight)
    Mechanical data
    Dimensions 17,5/L=83mm
    Weight 60g
    Housing Material Stainless steel AISI 316L / PA12 plug
    Connections M12 plug
    Active Head Material PA12
    Operating temperature -25°C…+80°C (without freeze)
    Diameter/Dimension Ø 17,5mm
    Test/Approvals
    Approvals CE cULus ECOLAB Diversey
    EMC compatibility EN 60947-5-2
    Shocks and vibrations Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
    Degree of protection IP68, IP69K
    Accessories
    Supplied Accessories
    Generical Data
    Dimensions 17,5/L=83mm
    Operating Temperature - 25°C…+ 80°C (Without freeze)
    Mechanical Protection IP68, IP69K
