Ph.M12,IR emiss.,M12,Emitter

Photo.M12,IR emiss.,M12 plug,Emitter
Photoelectric sensor M12 4 m Emitt. with adj. with check conn.M12

Article no.: DME/X0-1H
Orderable item
Register
  • Description

    Technical Features

    Detection properties
    Nominal sensing distance 4m
    Thermal drift of Sr ≤10% Sr
    Repeat Accuracy 5%
    Sensitivity adjustment Teach-in
    Application
    Function Principle Emitter
    Emitter/Receiver Emitter
    Optic position Axial
    Outputs
    Output type
    Electrical data
    Operating Voltage 10…30VDC
    No-Load supply current ≤ 30mA
    Max ripple content ≤10%
    LED indicators Yellow (Power ON)
    Time delay before availability ≤150ms
    Short-circuit protection Yes
    Reverse Polarity Protection Yes
    Emission LED Infrared (880nm)
    Impulsive Overvoltage Protection Yes
    Mechanical data
    Housing Material Nickel plated brass
    Connections M12 plug
    Active Head Material PMMA
    Diameter/Dimension M12
    Test/Approvals
    Approvals CE cULus
    EMC compatibility EN 60947-5-2
    Shocks and vibrations Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
    Accessories
    Supplied Accessories nuts M12 x 1
    Generical Data
    Dimensions M12x1/L=65,5mm
    Operating Temperature - 25°C…+ 70°C (Without freeze)
    Mechanical Protection IP67
