Photo.Mini,NPN+PNP-NC,M8,Reflx

Name: Photo.Mini,NPN+PNP-NC,M8,Reflx
SKU: QXC/C0-2F
Availability: BackOrder

Photo.Mini,NPN+PNP-NC,M8 plug,Reflex
Photoelectric sensor midi Retroreflective 4 m NPN/PNP NO 90° optic conn. M8 4pin

Article no.: QXC/C0-2F

Orderable item

Overview Axial and right angle optics 2 LEDs (threshold and signal margin) Visible red light in retro-reflective, polarized and through-beam models Long distances capability Precision beam Fast response time (0,75-0,5 ms) NPN-PNP selectable output High output current (>300 mA)

Technical Features

Detection properties

Nominal sensing distance	5m
Repeat Accuracy	≤ 5%
Sensitivity adjustment	Trimmer

Application

Function Principle	Polarized
Optic position	Radial 90°

Outputs

Output type	NPN/PNP Selectable NC
Output Function	NC
Switching frequency	750Hz
Response time	666µs

Electrical data

Operating Voltage	10…30VDC
No-Load supply current	≤ 20mA
Load current	≤300mA
Leakage current	≤ 100μA @ 30Vdc
Output voltage drop	≤1,2V@Iload=100mA
Max ripple content	≤10%
LED indicators	Red(output status) , Geen (stability)
Time delay before availability	≤200ms
Short-circuit protection	Yes
Reverse Polarity Protection	Yes
Emission	LED Infrared (880nm)
Interference to external light	3000lux Incandescent Lamp, 10000lux

Mechanical data

Dimensions	15x23x63
Weight	70g
Housing Material
Connections	M8 plug 4pin
Active Head Material	Acrylic
Operating temperature	- 25°C…+ 70°C ( without freeze)
Material	ABS
Diameter/Dimension	Cubic

Test/Approvals

Approvals	CE
EMC compatibility	EN 60947-5-2
Shocks and vibrations	Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
Degree of protection	IP65

Accessories

Supplied Accessories

ST70 mounting brakets and screws

Generical Data

Dimensions	15x23x40
Operating Temperature	- 25°C…+ 70°C (Without freeze)
Mechanical Protection	IP65
