Mini,NPN+PNP-NO,M12,Receiver

Name: Mini,NPN+PNP-NO,M12,Receiver
SKU: QXR/A0-1E
Availability: BackOrder

Photo.Mini,NPN+PNP-NO,M12 plug,Receiver
Photoelectric sensor midi Receiver 8 m NPN/PNP NO axial optic conn. M12

Article no.: QXR/A0-1E

Orderable item

Overview Axial and right angle optics 2 LEDs (threshold and signal margin) Visible red light in retro-reflective, polarized and through-beam models Long distances capability Precision beam Fast response time (0,75-0,5 ms) NPN-PNP selectable output High output current (>300 mA)

Technical Features

Detection properties

Nominal sensing distance	8m
Repeat Accuracy	≤ 5%
Sensitivity adjustment	Trimmer

Application

Function Principle	Receiver
Optic position	Axial

Outputs

Output type	NPN/PNP Selectable NO
Output Function	NO
Switching frequency	500Hz
Response time	1ms

Electrical data

Operating Voltage	10…30VDC
No-Load supply current	≤ 5mA
Load current	≤300mA
Leakage current	≤ 100μA @ 30Vdc
Output voltage drop	≤1,2V@Iload=100mA
Max ripple content	≤10%
LED indicators	Red(output status) , Geen (stability)
Time delay before availability	≤200ms
Short-circuit protection	Yes
Reverse Polarity Protection	Yes
Emission
Interference to external light	3000lux Incandescent Lamp, 10000lux

Mechanical data

Dimensions	15x23x77
Weight	70g
Housing Material
Connections	M12 plug
Active Head Material	Acrylic
Operating temperature	- 25°C…+ 70°C ( without freeze)
Material	ABS
Diameter/Dimension	Cubic

Test/Approvals

Approvals	CE
EMC compatibility	EN 60947-5-2
Shocks and vibrations	Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
Degree of protection	IP65

Accessories

Supplied Accessories

ST70 mounting brakets and screws

Generical Data

Dimensions	15x23x40
Operating Temperature	- 15°C...+ 55°C (Without freeze)
Mechanical Protection	IP65
