35x57x15,NPN-NO+NC,M12,S/Ns-LD
Cap.35x57x15,NPN-NO+NC,M12 plug,Sch/Nsch-LD
Capacitive sensor cubic Plastic DC 25 mm NPN NO+NC conn. M12
Orderable item
-
Description
Overview DC supply voltage Adjustable sensitivity Flat polycarbonate plastic housing
Technical Features
Detection propertiesNominal sensing distance 4…25mm Thermal drift of Sr < 20% Repeat Accuracy 5% Sensitivity adjustment Yes Hysteresis ≤ 20% OutputsOutput type NPN Output Function NO + NC Switching frequency 50Hz Electrical dataOperating Voltage 10...40Vdc No-Load supply current ≤ 10mA Load current ≤200mA Leakage current ≤ 10μA Output voltage drop 2,5Vmax @IL=200mA Max ripple content ≤10% LED indicators Yellow LED (object detected) Time delay before availability ≤100ms Short-circuit protection Yes, autoreset Reverse Polarity Protection Yes Impulsive Overvoltage Protection Yes Mechanical dataMounting Shielded/Unshielded Dimensions 55x35x15mm Weight 65g Housing Material PC Connections M12 plug Active Head Material PC Operating temperature -25°C…+80°C (without freeze) Storage temperature -40°C…+85°C Diameter/Dimension 55x35x15mm Test/ApprovalsApprovals CE cULus EMC compatibility IEC 60947-5-2 Degree of protection IP67 AccessoriesSupplied Accessories screw driver Generical DataDimensions 55x35x15mm Operating Temperature -25°C…+80°C (without freeze) Mechanical Protection IP67 -
