Saf,M18,Emitt,M12Plug,Type 2

Safety,M18,Emitter,M12 plug,Type 2
Safety sensor Type 2 PLc Emitt.M18 5m plast. 90° conn. M12 I/O IEC61131-2 f = 123 kHz (do not use in conjunction with SBCR03 control unit)

Article no.: SH2/E-2EIC
Orderable item
Register
  • Description
    Overview M18 Models 10 m (axial optic) and 5 m (radial optic) operating distance M30 models 60 m operating distance EN50100 Category 2 and Category 4 compliant LED indicators Plastic and Metal Housing Inputs and Outputs IEC61131-2 compliant and adaptable with any safety module To be used together with a Category 2 or Category 4 safety control unit to obtain a safety system EN ISO 13849 compliant

    Technical Features

    Detection properties
    Nominal sensing distance 5m (ExG=2)
    Thermal drift of Sr ≤ 10%
    Resolution Single-beam
    controlled height Single-beam
    Effective Aperture Angle ≤ ±5°
    Effective Aperture Angle Typical ±1,8°
    Application
    Function Principle Emitter
    Notes not working with SBCR03 control unit. To be used with external safety control unit with automatic optics test function
    Description M18 Type 2 Safety Photocell Emitter
    Safety parameters
    Type Type 2 safety photocell
    SIL 1
    SILCL 1
    PL c
    PFHd 1,00E-06
    MTTFd 20 years
    Electrical data
    Operating Voltage 10 … 30 Vdc
    No-Load supply current ≤ 25mA
    Max ripple content ≤ 5 Vpp
    LED indicators Yellow (power)
    Emission Red
    Test levels <5V emission inactive >15V emission active
    Mechanical data
    Dimensions M18
    Housing Material PBT
    Connections M12 plug
    Active Head Material Glass
    Operating temperature -20°C … +55°C
    Storage temperature -40°C … +75°C
    humidity 15% … 95%
    Test/Approvals
    Approvals CE, TÜV
    Shocks and vibrations 10g - 16ms (according to IEC600068-2-29) 10Hz…55Hz - 1 oct/min - 0,35mm (according to 60068-2-6)
    Degree of protection IP67
    Accessories
    Supplied Accessories 2 x nuts
    Generical Data
    Dimensions M18
    Operating Temperature -20…+55°C (Without freeze)
    Humidity 15% … 95%
    Mechanical Protection IP67
